Ultimate9 LED Light Bar 20"

Ultimate9 LED Light Bar 20"

Face the challenges of the dark with the Ultimate9 LED Light Bars.

Our sleek, single row LED bars incorporate a screw-less bezel design for superior sealing against the elements, fitted with Gore® PolyVents for ultimate housing ventilation.

Encased in high-grade aluminium and protected by impact-resistant Lexan® Polycarbonate lenses, their rugged construction will last for years to come.



Features:
  • Water & Dust Protection: Tested to the highest IP ratings, IP68 and IP69K.
    IP68 for long term submersion and total dust ingress.
    IP69K for stream jet cleaning.
  • Ventilation: Gore® PolyVent breather valve equalises internal pressure to prevent seal failure, moisture and dust ingress as the aluminium housing heats and cools - eliminating condensation & fogging.
  • Housing: 6063-grade aluminium housing with 304 Stainless Steel fasteners. Overlaid with a UV & corrosion resistant Dupont® coating.
  • Lens: GE Lexan® Polycarbonate lenses are virtually indestructible, UV, scratch and impact-resistant; they negate the need for additional protective covers.
  • Optics: Flood & Spot reflector beam combination with 20°(Flood) & 8°(Spot) spreads.
  • Technology: Grade A Osram 5W LED chips & sealed DT connectors.



Specifications:

  • Input Power: 9-36V
  • Beam Pattern: Flood & Spot Combination
  • Beam Spread: 8° Spot & 20° Flood
  • Power: 100W
  • Current Draw: 6.6A @ 13.2V
  • Raw Lumen: 9,520 lm
  • Effective Lumen: 5,015 lm
  • Beam @ 1 Lux: 528m
  • LED Chips: Osram 5W
  • Colour Temp: 6000-6500K
  • Housing Material: 6063 Aluminium
  • Housing Coating: DuPont®
  • Lens Material: GE Lexan® Polycarbonate
  • IP Rating: IP68 / IP69K
  • Ventilation: Gore® PolyVent
  • Weight: 1.68Kg
  • Body Dimensions: (L)560 x (H)46 x (W)49mm
  • Lens Dimensions: 20" (508mm)
  • Connector Type: DT Sealed
  • Operating Temp: -40ºC - 145ºC
  • Certification: CE, RoHS, RCM



Required Harness: Ultimate9 Twin Output Harness



Kit Includes:

• LED Light Bar
• Side-Mount Brackets & Hardware

Harnesses available separately*



What Harness Do I Need?*

Ultimate9 20", 26", & 30" LED Light Bars, more often fitted at the front of vehicles, utilise the Twin Output Harness



Note: The Twin Output Harness is capable of powering two 20", 26", or 30" bars.

Select Options:
From $38.08

Original: $126.92

-70%
Ultimate9 LED Light Bar 20"—

$126.92

$38.08
